Product Introduction The Series offers the proven, 100% leak-proof performance of a magnetic drive pump in an innovative vertical inline configuration. This design provides a dramatic reduction in footprint, making it the ultimate space-saving solution for chemical transfer. By integrating directly into the pipeline like a valve, the pump eliminates the need for complex piping and foundations. It is the perfect choice for crowded industrial facilities, compact OEM skid systems, and any application where performance cannot be sacrificed for space.
Design Philosophy & Construction The pump takes the core technology of a magnetic drive pump and reorients it for maximum efficiency in both space and piping design.
- Vertical Inline Layout: The pump is designed to be mounted vertically with the motor on top. The key feature is that the suction and discharge nozzles are on the same centerline (inline). This allows the pump to be installed as part of a straight pipe run, supported entirely by the pipeline itself, which eliminates the need for a concrete foundation or baseplate.
- Proven Magnetic Drive Core: Internally, the pump uses the same reliable sealless magnetic coupling as its horizontal counterparts. An external magnet ring driven by the motor transmits torque through a solid containment shell to an internal magnet ring on the impeller, ensuring zero leakage.
- Simplified Installation: The inline design drastically simplifies piping. It removes the need for the 90-degree elbows and extra supports required for a standard end-suction pump, saving on both material and labor costs during installation.
Key Features & Benefits
- Minimal Footprint: The vertical inline design saves a significant amount of valuable floor space compared to traditional horizontal pumps, making it ideal for crowded plant layouts.
- Simplified Piping: Reduces the complexity and cost of piping installation by eliminating elbows and foundations.
- 100% Leak-Proof Operation: Provides the absolute safety and fluid containment of a sealless magnetic drive, protecting personnel and the environment.
- No Alignment Necessary: As a close-coupled, foundation-less unit, the time-consuming and critical task of shaft alignment is completely eliminated.
- Easy to Service: The pump can often be serviced by simply removing the motor and drive assembly, leaving the pump casing in the pipeline.
Common Applications The pump is the preferred choice when space is a primary consideration:
- OEM & Skid-Mounted Systems: Perfect for integration into compact, pre-fabricated systems for chemical dosing, filtration, and purification.
- Plant Retrofits and Upgrades: An excellent solution for adding pumping capacity to existing facilities where floor space is not available.
- Shipbuilding and Marine: Used in the tight confines of engine rooms and utility spaces on ships and offshore platforms.
- Tank Farm Manifolds: Ideal for installation in dense networks of pipes for fluid transfer and circulation.
- HVAC and Utility Services: For circulating thermal fluids or treated water in building utility systems.
